USB3.0 pci express card adapter

FOB Reference Price:Get Latest Price
US $6.5-9 / Cases | 100 Case/Cases (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Products Status:
Stock
Brand Name:
OEM
Model Number:
MP305
Place of Origin:
Guangdong, China (Mainland)
Color:
black/red/green/blue
Warranty:
one year
Transfer speed:
5Gbp/s
Support interface:
PCI Express
Expand port:
4ports USB3.0
Application:
Desktop
Certificate:
CE,RoHS
Support System:
Window 2000/XP/VISTA/7
Operation environment:
0°C/50°C(use); -20°C/70°C(storage)
OEM/ODM:
Available
Packaging & Delivery
Packaging Details
1.one piece packed in one color box;
2.or to your special require
Port
Shenzhen
Lead Time :
timely within 5-7 working days after payment is confirmed

Specifications

USB3.0 pci express card adapter
Transfer rate up to 5Gbps
Main Chipest:VL800
one year warranty
CE,RoHS

4-port USB3.0 PCI Express card, 1years warranty, VLI800 chipset

Specifications

4ports USB3.0 can connect with 4pcs USB device at same time
USB3.0 interface transfer rate up to 5Gbps, compatible USB2.0/1.1



Product Introduction

Meitk released the newest desktop 4ports USB3.0 high speed express card. USB3.0 has already become one of the most popular interfaces in present IT world. Its previous generation USB2.0 is the interface with widest range of users in IT products, and nearly over 2billions USB devices sell out till now. USB3.0 will replace USB2.0 gradually, because it can reach the high speed which USB2.0 can’t reach. First its theoretical transfer rate up to 5Gbps, much higher than USB2.0 480Mbps, and also higher than eSATA 3Gbps speed. Besides, USB3.0 is compatible with USB2.0 and 1.1 standards, that is to say you can use it in your USB2.0 interface.



Product Features

  1. Conform to PCI-Express standard 2.0 version
  2. Product main control IC: VLI800
  3. 4ports USB3.0 can connect with 4pcs USB device at same time
  4. USB3.0 interface transfer rate up to 5Gbps, downward compatible with USB2.0/1.1
  5. USB3.0 use big 4pin interface for power supply
  6. Support USB hot-swap, plug and play
  7. Low power consumption and energy saving product
  8. Window 2000/XP/VISTA/7



Product Application

By using MP305, you can make your mainboard instantly upgrade to USB3.0 high speed, and enjoy the great capacity and high efficient storage ability. This product fit for multimedia video edit system, server database, DVR data storage, 2D/3D cartoon, artiest plot and system data backup using environment, and support Windows! It makes desktop mainboard upgrade to USB3.0 easily.



Product Specification

Product Name

4 port USB3.0 PCI Express Adapter/card

Product Mode

MP305

Product UI

express card

Product Dimension

120*70* 19mm

Product Weight

58g

Support System

Window 2000/XP/VISTA/7

Safety Certificate

CE and FCC approval

Operation environment

0°C/50°C(use); -20°C/70°C(storage)



Product Accessories

  1. Express card*1
  2. User manual*1
  3. Drive disk*1
  4. Install screw*1

Pictures
