PCI-E USB3.0 expansion express card

FOB Reference Price:Get Latest Price
US $5.8-6.5 / Cases | 100 Case/Cases (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Products Status:
Stock
Brand Name:
meitk
Model Number:
MP303
Place of Origin:
Guangdong, China (Mainland)
Product color:
Red/green
Product target:
desktop
Transfer rate:
5000/5Mbps. 480/12/1
USB power output:
900mA supreme 5V
Main control chip:
NEC D720200F1
Product operation:
easy
Standard:
PCI - Express standard version 2.0
Package:
ESD bag/white box
Warranty:
One year
Transfer speed:
5GBp/s
Packaging & Delivery
Packaging Details
Packed in a poly bag or to your special require
Port
shenzheen
Lead Time :
timely within 2 business days after payment is confirmed

Specifications

PCI-E USB3.0 expansion express card
1.samll order can accept
2.fast delivery time
3.offer factory price
4.supply warranty

PCI-E USB3.0 expansion express card

Description



The 2 port Power over eSATA ( eSATAp) PCIe card expands your PC with two external Power eSATA ports. These ports enable you to connect not only Power Over eSATA devices but also the standard devices with built-in eSATA and USB A Type connectors. Power over eSATA port is the hybrid of eSATA and USB2.0 and it is compliance with 5V / 12V standard, as long as it co-works with 5V / 12V Power over eSATA cable, then it doesn't require separate power when connecting to 2.5", 3.5" or 5.25" hard drive under eSATA transmission.



Additionally, with 1 internal IDE port and the RAID function enhance the application of EP-221.





Specification



Application

Add-on 2 external Power over eSATA (eSATAp) ports to the PC system

PC Interface

PCI Express 1.1 specification, Standard 121mm Bracket

External Port

2 x external Power over eSATA (eSATAp) port

(Compatible with Power over eSATA (eSATAp) / USB A Type / eSATA connector)

Internal Port

1 x IDE (PATA) connector

Bus Power Support

5V / 12V

Data transfer rate

USB2.0 up to 480 Mbps ; eSATA up to 3Gbps

SATA Features

Fully compliant with SATAI/ II speed

Supports 2-port 3.0Gbps SATA II interface

Supports two independent SATA II channels (separate logic and FIFO)

Supports Native Command Queue (NCQ) on SATA II port

Supports SATA II Gen2i and Gen2m (External SATA Connection, eSATA)

Supports Port Multiplier with Command-based Switching on SATA II port

Supports up to UDMA6 transfer mode of PATA

USB Features

Driverless Installation

Data transfer rate can be 1.5/12/480Mbps

Compliant with OHCI Specification for USB Rev 1.0a

Support USB OHCI & UHCI modes

Chains up 127 devices

Support devices hot swap

Easy plug and play installation

RAID Support

RAID 0 / 1,JBOD and SATA Port-Multiplier

System Request

Windows 2K / Server 2003 / XP / Server 2008 / Vista / 7 , MAC 10.4.6 or later &

Linux system

PC with a free PCI Express slot

Motherboard with a free USB pin header

Available 12V power cable (with big 4 pin power plug)
